A CAD workstation needs to feel responsive while modelling and have enough room for the assemblies you actually open. I would choose the software route first, then buy the processor, memory and graphics combination around it. AutoCAD, SOLIDWORKS and Revit deserve different parts decisions.

Complete the creative desk with a suitable monitor, the colour workflow and a work mouse. For pen input, compare drawing tablets; for moving projects, choose the portable drive around its host interface.

Start by naming the application and project. Predominantly 2D drafting in AutoCAD is a different purchase from a large SOLIDWORKS assembly, a Revit building model or a separate rendering job. Write down what slows your current work: opening files, editing a feature, navigating a view, running a solver or producing renders. Each answer moves the spending towards a different component.

For business-critical SOLIDWORKS work, decide whether a vendor-supported workstation is a requirement before building. The certification list identifies exact combinations rather than declaring every professional graphics card suitable for every version. For a self-build, use that list to choose the card and driver, and understand the support arrangement you need. The dedicated AutoCAD and Revit guides below narrow the parts plan further.

64GB is the roomy starting point for this mixed CAD tower, while 32GB is the lower-cost drafting route. Large projects can justify 96GB or a different workstation platform. Keep model complexity and the applications open together ahead of a universal file-size rule.

Crucial Pro 64GB DDR5-5600 is the roomy two-stick workstation route. The purchase makes sense when several applications, sizeable projects or virtual machines need space at the same time.

Use the board’s memory support list and the processor’s memory guidance for the exact kit. A lower advertised transfer rate can be a reasonable trade for the capacity needed to keep work in memory.

Choose the memory kit for this workload

Plan the RAM capacity for the work kept open together and the supported module arrangement. The profile guide covers setup once all memory is working at defaults.

Put the OS, applications and active projects on the NVMe drive, with versioned copies elsewhere. Shared project data can live on a properly managed network destination, but a network archive and a fast local working drive have different roles. Confirm the software’s supported project-sharing workflow before relocating active files.

The WD Black SN850X 2TB is my active-project drive choice. Its role is to hold the files the PC reads and writes during work, rather than use an expensive SSD as the only home for every finished project.

A motherboard heatsink helps the drive manage sustained work. Check the slot arrangement before installing several M.2 drives, since lane sharing and disabled ports vary by board.

Compare storage for this build · Distinguish memory and storage upgrades

Choose enough working storage, then check the exact SSD format/interface. The PCIe comparison helps decide whether the speed premium serves this build.

The Gigabyte B650 Eagle AX is the standard AM5 starting board. I would buy it when its storage, networking and USB layout cover the job, then keep the rest of the budget for the processor, memory and active project drive.

Confirm CPU support on the installed BIOS and map the M.2 slots and expansion cards before adding devices. More expensive chipset branding is useful only if the extra connections have a job.

Map the devices you actually plan to connect: displays, USB equipment, storage and expansion cards. Make the CPU, board and memory a matched platform before choosing optional accessories. A thick graphics card can cover a slot that otherwise looks available.

Choose the board and useful features · Understand the connections worth buying

Read the board/platform guide and check the case’s internal connections. PCIe and M.2 sharing keeps the planned drives and expansion cards usable together.

This is the starting basket for the route described here. Choose the alternative parts as a complete matched configuration, keeping the board, memory, cooling and power changes together. The monitor, operating system and any equipment you already own should be counted in the total purchase plan.

For the other decisions in this cluster, use the processor shortlist, the graphics shortlist and the specialist buying guide.

Install the application-supported graphics driver and establish a stable baseline before importing custom workspaces and plugins. Open a representative model, navigate it, regenerate or update it, then run the processing stage that matters in your workflow. Record the useful bottleneck rather than replacing parts by guesswork.

Use the AutoCAD guide for drafting-led systems and the Revit guide for building models. For a SOLIDWORKS-led build, keep the certification check with the graphics order and choose memory around the assembly. Rendering can justify a separate CPU or GPU tier without forcing that spend on every designer.

Follow the beginner assembly guide · Check the complete parts fit
